Study settings explained

This page explains each option on the Study Settings screen, in the order you see it, and what changes for each study type. Most options can be changed later, from the first step of the study.

Jump to: Allow participation from | Facial coding | Random order | Head position | External tool integration | Eye-tracking setup | Settings by study type

#Study name

The name shown in your dashboard and in reports. It has no effect on results.

#Allow participation from

Choose which devices participants may use: desktop, smartphone held vertically, smartphone held horizontally, or tablet.

Your study type decides what is available. Some types allow desktop only, and some devices need a licence that includes them. Tablet support is still in BETA, so treat it as a work in progress rather than a guarantee.

#Use stored calibration data between studies

Participants who already calibrated in an earlier study do not calibrate again. A quick validation step runs instead, so tracking quality is still checked before the study starts.

#Enable Facial Coding module

Uses the webcam to collect information about emotions. It needs a licence that includes the Facial Coding module.

It does not work with RealEye Webcam v3. When v3 is selected, the option is disabled and the screen tells you that facial coding works only with RealEye Webcam v1. If you need facial coding, choose RealEye Webcam v1 in Eye-tracking setup. See Facial coding and RealEye Webcam v1 vs v3.

#Show elements in random order

Each participant sees the items in a different order, so the order itself does not push the results one way. Items you pin stay where you put them. You can still see the order a participant saw in their recording.

#Show separator between items

Shows a separator between items so the eyes can rest between images. How long it stays is set per item, and the default is 1.5 seconds. When this is off, no separator appears, even if a separator time is set on an item. Separator length is set in Item settings.

#Ask participants about name, gender and age

Adds a short survey at the end of the test.

It does not work with RealEye panelists. They do not provide this data under the privacy policy, so the survey is for participants you invite yourself.

#Control participants head position

On by default, and recommended. If a participant moves their head too much, a prompt asks them to correct their position. Head movement affects tracking quality, so this is worth leaving on. See How to get accurate results.

#Let participants see their results (BETA)

Participants can watch their recordings when the study ends. If you use a finish URL, that link appears as a manual click. With the option off, participants get the thank you page or your redirect instead.

#Open tested website with test parameters (BETA)

For Screen Recording studies. Passes the values in the participation link through to the website being tested, so the site can react to them, for example by showing a specific version of a page.

You choose whether RealEye also attaches the participant ID and the quality grade, and that is on by default. It changes nothing on the tested website by itself: that site has to be prepared to read those values. See Add parameters and tags to the Participation Link for how the values are passed.

#Enable external tool integration

Connects the study to a survey or another tool. You get a finish URL, a skip test URL, a quota full URL, and a screen out URL, and you can attach the participant ID and quality grade, attach shelf shopper metrics, redirect by quality, and let participants skip the test.

Set aside a little time for this one. Connecting an external survey normally needs someone with IT knowledge, for example whoever runs your survey platform or your IT support team, because you copy the study link into the survey and paste the return URLs back into RealEye.

RealEye panelists cannot be used while this is on, so you invite your own participants. See Connecting a study with an external survey, Survey routing and parameters, and Add parameters and tags to the Participation Link.

#Additional Instruction step

Adds one extra screen at the start with your own headline, text, and optional icon. Use it to give a specific task, for example which product to look for.

#Eye-tracking setup

Chooses the eye tracker the study runs on. RealEye Webcam v3 is the default for new desktop studies.

RealEye Webcam v1 is needed for facial coding, and for phones and tablets, because v3 supports neither. Hardware eye trackers appear in this list when that integration is enabled.

#Optional intro message

Shown to participants after calibration and before the test. This is where the main instruction goes.

#Optional message after the test

Shown on the thank you page.

It does not appear when a finish URL is set, because participants are redirected then.

#Settings that differ by study type

The options above exist for every study type. Each study type also adds or changes part of the setup, as follows.

Images and Videos. Standard item settings apply: display time, an optional instruction before each item, a follow-up survey, finish on click or on a keypress, and a minimum display time. You can use up to 300 items in one study. See Item settings.

Interactive Mockup. You draw clickable areas that move participants between screens, and set rules such as which screen follows a click and how long a screen stays on screen. You can also highlight the clickable areas for a second after a click. Up to 300 pages per study. See Mockup studies and Item mapping.

Embedded Website. You add the RealEye JavaScript SDK to your own website, the site has to allow being shown inside another page, and you map the parts you want to measure as Areas of Interest. Participants browse the live site and you still get combined results. See Embedded Website tests for aggregated results.

Screen Recording. Adds two options: Enable Voice Over, which records what participants say, and Open tested website with test parameters, which passes link values to the site. Desktop or laptop only, and there are no combined results across participants. See Website testing best practices.

Instagram Mockup. You upload images and videos that become a scrollable feed. RealEye records gaze, clicks, and scrolling, and you get combined results. See Comparing RealEye study types.

Shelf testing. You build shelves from product pictures and a spreadsheet. Up to 10 shelves, each with its own display time, and participants can add to cart, select, put back, and check out. See Shelf Testing: how to build the spreadsheet.
